Description
THIEME 500
Semi-automatic, clamshell screen printing machine used for various applications
- Compact formats
- Low profile print head rise
- User friendly operation
- Fast production speeds
- Shorter set-up times due to an easily-accessed screen-frame mounting system
- Superior work results using the patented THIEME Hi-Tech Squeegee Unit
- Flexible operation by means of adjustable drive systems
- A modern, patented safety equipment that neither impact sight nor operation
- A complete machine re-design to meet almost all demands in the flatbed screen printing industry
Why THIEME 500?
- Small footprint
- User friendly operation
- Fast production speed
- Optimal accessibility by use of the Thieme safety system
- Thieme quality žMade in Germanyœ
Specifics
- Short set-up times
- Height-adjustable printing table
- Proven THIEME squeegee Unit
- Infinitely adjustable print speed and squeegee angle
- Machine comes ready to connect
- Pneumatic frame clamping
- Print stroke infinitely adjustable via analog switches
Technical data
| Type of machine | 510 | 520 | 530 |
|---|---|---|---|
| Print size [mm] | 550×750 | 750×1050 | 1000×1400 |
| Frame size max. [mm] | 1000×1100 | 1200×1400 | 1450×1750 |
| External dimensions L x W [mm] | 1560×1360 | 1760×1660 | 2010×2010 |
| Weight [kg] | 620 | 680 | 770 |
| Table adjustment in 3 axes [mm] | +/- 10 | ||
| Squeegee speed [m/sec] | 0,1-1,25 | ||
| Range of substrate thickness max. [mm] | 40 | ||
| Frame hight max. [mm] | 50,4 | ||
| Power supply [V] | 400/230 | ||
| Print speed on request. All technical information are not binding and subject to change. |
|||
